温馨提醒：图片仅供参考，商品以实物为准
HY18080MSMD3225GB1R30
18.08MHz ±10ppm 15pF
SMT扩展库SMT补贴嘉立创PCB免费打样
- 描述
- 18.080MHZ SMD3225 15PF 10PPM
- 商品型号
- HY18080MSMD3225GB1R30
- 商品编号
- C5265868
- 商品封装
- SMD3225-4P
- 包装方式
- 编带
- 商品毛重
- 0.045克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 无源晶振 | |
| 晶振类型 | 贴片晶振 | |
| 频率 | 18.08MHz | |
| 常温频差 | ±10ppm |
| 属性 | 参数值 | |
|---|---|---|
| 负载电容 | 15pF | |
| 频率稳定度 | ±30ppm | |
| 等效串联电阻(ESR) | 40Ω | |
| 工作温度 | -40℃~+85℃ |
