YASPI0421S-R40M
YASPI0421S-R40M
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 车规级 一体成型电感 0.40uH 饱和电流：12.6A 温升电流：10.7A 直流电阻：7.2mΩ 400nH
- 品牌名称
- YJYCOIN(益嘉源)
- 商品型号
- YASPI0421S-R40M
- 商品编号
- C55157810
- 商品封装
- SMD,4.2x4mm
- 包装方式
- 编带
- 商品毛重
- 0.4399克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 一体成型电感 | |
| 电感值 | 400nH | |
| 精度 | ±20% | |
| 额定电流 | 9.6A |
| 属性 | 参数值 | |
|---|---|---|
| 饱和电流(Isat) | 10.8A | |
| 直流电阻(DCR) | 7.2mΩ | |
| 类型 | 一体成型电感 |
