YASPI0630S-1R5M
YASPI0630S-1R5M
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 车规级 一体成型电感 1.5uH 饱和电流：11.6A 温升电流：10.6A 直流电阻：12.5mΩ
- 品牌名称
- YJYCOIN(益嘉源)
- 商品型号
- YASPI0630S-1R5M
- 商品编号
- C55157828
- 商品封装
- SMD,7x6.6mm
- 包装方式
- 编带
- 商品毛重
- 1.189克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 一体成型电感 | |
| 电感值 | 1.5uH | |
| 精度 | ±20% | |
| 额定电流 | 9.5A |
| 属性 | 参数值 | |
|---|---|---|
| 饱和电流(Isat) | 9.9A | |
| 直流电阻(DCR) | 12.5mΩ | |
| 类型 | 一体成型电感 |
