温馨提醒：图片仅供参考，商品以实物为准
LCK-WF-A2002WV-3PA
1x3P 间距:2mm 系列:HY
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- WAFER HY带扣2.00直针3P
- 品牌名称
- LCKELEC(联晟欣)
- 商品型号
- LCK-WF-A2002WV-3PA
- 商品编号
- C54769954
- 商品封装
- 插件,P=2mm
- 包装方式
- 袋装
- 商品毛重
- 0.2131克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 线对板针座 | |
| 插针结构 | 1x3P | |
| 间距 | 2mm | |
| 参考系列 | HY | |
| 总PIN数 | 3P | |
| 排数 | 1 | |
| 每排PIN数 | 3 | |
| 行距 | 2mm | |
| 额定电流 | 2A | |
| 触头材质 | 磷青铜 |
| 属性 | 参数值 | |
|---|---|---|
| 触头镀层 | 锡 | |
| 工作温度 | -25℃~+85℃ | |
| 额定电压 | 250V | |
| 塑料材质 | PA66 | |
| 阻燃等级 | UL94V-0 | |
| 颜色 | 白色 | |
| Z轴-板上高度 | 7.8mm | |
| X轴-板上底边长度(间距线) | 8mm | |
| Y轴-板上底边宽度 | 5.1mm |
