温馨提醒：图片仅供参考，商品以实物为准
XL-3512RGBW-2812B
3512幻彩雾状
SMT扩展库SMT补贴嘉立创PCB免费打样
- 描述
- 3512幻彩雾状 内置驱动IC WS2812B
- 品牌名称
- XINGLIGHT(成兴光)
- 商品型号
- XL-3512RGBW-2812B
- 商品编号
- C49237874
- 商品封装
- SMD
- 包装方式
- 编带
- 商品毛重
- 0.05196克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | RGB LED(内置IC) | |
| 波长 | R:620nm~625nm；B:465nm~475nm；G:515nm~525nm | |
| 发光强度 | G:600mcd~800mcd；R:200mcd~300mcd；B:100mcd~200mcd | |
| PWM频率 | 1.5kHz | |
| 数据速率 | 800Kbit/s | |
| 工作电压 | 4.5V~5.5V | |
| 静态电流 | 0.5mA |
| 属性 | 参数值 | |
|---|---|---|
| 抗静电能力 | 2000V | |
| 工作温度 | -40℃~+85℃ | |
| 峰值波长 | R:625nm；B:470nm；G:525nm | |
| 发光角度 | 120° | |
| 长度 | 3.5mm | |
| 宽度 | 1.6mm | |
| 高度 | 1.2mm |
