温馨提醒：图片仅供参考，商品以实物为准
01.X.SA.120ILVF0013528750
KC料 13.52875MHz ±15ppm 20pF
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 49S 13.528750MHz 20pF ±15ppm (±30ppm -40~85) FUND
- 品牌名称
- CREC(晶宝)
- 商品型号
- 01.X.SA.120ILVF0013528750
- 商品编号
- C7462574
- 商品封装
- HC-49S
- 包装方式
- 袋装
- 商品毛重
- 0.6259克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 无源晶振 | |
| 频率 | 13.52875MHz | |
| 常温频差 | ±15ppm | |
| 负载电容 | 20pF |
| 属性 | 参数值 | |
|---|---|---|
| 频率稳定度 | ±30ppm | |
| 等效串联电阻(ESR) | 50Ω | |
| 工作温度 | -40℃~+85℃ |
应用领域
-蓝牙、汽车、无线通信-计算机、调制解调器、通信设备-机顶盒、数字增强无绳通信(DECT)/无线数据(WD)
