温馨提醒：图片仅供参考，商品以实物为准
CM4026M00075001
26MHz ±10ppm 7.5pF
SMT扩展库SMT补贴嘉立创PCB免费打样
- 品牌名称
- HUAXIN(华昕)
- 商品型号
- CM4026M00075001
- 商品编号
- C7294633
- 商品封装
- SMD2520-4P
- 包装方式
- 编带
- 商品毛重
- 0.037633克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 无源晶振 | |
| 晶振类型 | 贴片晶振 | |
| 频率 | 26MHz | |
| 常温频差 | ±10ppm |
| 属性 | 参数值 | |
|---|---|---|
| 负载电容 | 7.5pF | |
| 频率稳定度 | ±30ppm | |
| 等效串联电阻(ESR) | 60Ω | |
| 工作温度 | -40℃~+85℃ |
