温馨提醒：图片仅供参考，商品以实物为准
HSP2R7V155DS6C12HB
1.5F -10%~+30% 2.7V
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 日本进口碳粉，干法工艺大容量，低内阻，长寿命，低漏电流
- 品牌名称
- HEGA(和佳)
- 商品型号
- HSP2R7V155DS6C12HB
- 商品编号
- C55471408
- 商品封装
- 插件,D6.3xL12mm
- 包装方式
- 盒装
- 商品毛重
- 0.676克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 超级电容器 | |
| 容值 | 1.5F | |
| 精度 | -10%~+30% | |
| 额定电压 | 2.7V | |
| 漏电流 | 3uA@72hrs | |
| 等效串联电阻(ESR) | 190Ω@1kHz |
| 属性 | 参数值 | |
|---|---|---|
| 工作寿命 | 1000hrs@65℃ | |
| 循环寿命(次) | 500000次 | |
| 工作温度 | -40℃~+65℃ | |
| 电容体直径 | 6.3mm | |
| 脚间距 | 2.5mm | |
| 电容体高度 | 12mm |
