温馨提醒：图片仅供参考，商品以实物为准
X1321FVS-2x18S-C43D48
2x18P 间距:1.27mm 立贴
SMT扩展库PCB免费打样
私有库下单最高享92折
- 商品型号
- X1321FVS-2x18S-C43D48
- 商品编号
- C55381487
- 商品封装
- SMD,P=1.27mm
- 包装方式
- 管装
- 商品毛重
- 1.55克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 排母 | |
| 插孔结构 | 2x18P | |
| 间距 | 1.27mm | |
| 圆孔/方孔 | 方孔 | |
| 安装方式 | 立贴 | |
| 排数 | 双排 | |
| 总孔位数 | 36P | |
| 额定电流 | 1A |
| 属性 | 参数值 | |
|---|---|---|
| 插孔方向 | 顶部 | |
| 塑高 | 4.3mm | |
| 触头材质 | 磷青铜 | |
| 触头镀层 | 金 | |
| 工作温度 | -40℃~+105℃ | |
| 附加特征 | 带柱 | |
| 针脚长度 | - |
