ELF1V680M061100I
68uF/35V/6.3×11/105℃/±20%/PET/3000小时
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 68uF/35V/6.3×11/105℃/±20%/PET/3000小时
- 品牌名称
- TOPAZCON(黄宝石)
- 商品型号
- ELF1V680M061100I
- 商品编号
- C55265424
- 商品封装
- 插件,D6.3xL11mm
- 包装方式
- 袋装
- 商品毛重
- 0.551515克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 直插铝电解电容 | |
| 容值 | 68uF | |
| 精度 | ±20% | |
| 额定电压 | 35V | |
| 纹波电流 | 310mA@100kHz | |
| 等效串联电阻(ESR) | 460mΩ@100Hz |
| 属性 | 参数值 | |
|---|---|---|
| 脚间距 | 2.5mm | |
| 电容体直径 | 6.3mm | |
| 电容体长度 | 11mm | |
| 工作寿命 | 3000hrs@105℃ | |
| 工作温度 | -40℃~+105℃ |
