温馨提醒：图片仅供参考，商品以实物为准
PM200V-11-10-H635
1x10P 间距:2mm 直插
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 排母2.0mm直插 1x10P H6.35mm W2.0 Y型 PC2.9 镀金 管装
- 品牌名称
- XFCN(兴飞)
- 商品型号
- PM200V-11-10-H635
- 商品编号
- C55218692
- 商品封装
- 插件,P=2mm
- 包装方式
- 管装
- 商品毛重
- 0.878715克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 排母 | |
| 插孔结构 | 1x10P | |
| 间距 | 2mm | |
| 圆孔/方孔 | 方孔 | |
| 安装方式 | 直插 | |
| 排数 | 单排 | |
| 总孔位数 | 10P |
| 属性 | 参数值 | |
|---|---|---|
| 额定电流 | 2A | |
| 插孔方向 | 顶部 | |
| 塑高 | 6.35mm | |
| 触头材质 | 黄铜 | |
| 工作温度 | -40℃~+105℃ | |
| 针脚长度 | 2.9mm |
