温馨提醒：图片仅供参考，商品以实物为准
APGL1005-5N6CETD9
精度：±0.2nH
SMT扩展库PCB免费打样
私有库下单最高享92折
- 品牌名称
- APV(爱普微)
- 商品型号
- APGL1005-5N6CETD9
- 商品编号
- C54951926
- 商品封装
- 0402
- 包装方式
- 编带
- 商品毛重
- 0.01188克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 贴片电感 | |
| 电感值 | 5.6nH | |
| 额定电流 | 620mA | |
| 直流电阻(DCR) | 200mΩ |
| 属性 | 参数值 | |
|---|---|---|
| 品质因数 | 8@100MHz | |
| 自谐振频率 | 4GHz | |
| 类型 | 叠层电感 |
