温馨提醒：图片仅供参考，商品以实物为准
BCMF121006900M00
BCMF121006900M00
SMT扩展库PCB免费打样
私有库下单最高享92折
- 品牌名称
- EMTEK(兆欣)
- 商品型号
- BCMF121006900M00
- 商品编号
- C54900509
- 商品封装
- SMD-4P,1.3x1mm
- 包装方式
- 编带
- 商品毛重
- 0.034475克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 共模滤波器 | |
| 线路数 | 2 | |
| 额定电流 | 100mA | |
| 阻抗@频率 | 90Ω@100MHz |
| 属性 | 参数值 | |
|---|---|---|
| 额定电压 | 5V | |
| 直流电阻(DCR) | 4Ω | |
| 工作温度 | -40℃~+85℃ | |
| 绝缘电阻 | 10MΩ |
