温馨提醒：图片仅供参考，商品以实物为准
CD288H2AM181G200T
180uF ±20% 100V
SMT扩展库SMT补贴嘉立创PCB免费打样
- 描述
- 高频低阻，标准品 3000H at 105℃
- 品牌名称
- 创慧电子
- 商品型号
- CD288H2AM181G200T
- 商品编号
- C51026457
- 商品封装
- 插件,D10xL20mm
- 包装方式
- 袋装
- 商品毛重
- 2.84克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 直插铝电解电容 | |
| 容值 | 180uF | |
| 精度 | ±20% | |
| 额定电压 | 100V | |
| 脚间距 | 5mm |
| 属性 | 参数值 | |
|---|---|---|
| 电容体直径 | 10mm | |
| 电容体长度 | 20mm | |
| 工作寿命 | 3000hrs@105℃ | |
| 工作温度 | -40℃~+105℃ |
