RA101M250E060R1Z00ZZ
100uF ±20% 25V
SMT扩展库PCB免费打样
私有库下单最高享92折
- 描述
- 高温高压品，125℃ at 2000H
- 品牌名称
- CH(创慧电子)
- 商品型号
- RA101M250E060R1Z00ZZ
- 商品编号
- C49435112
- 商品封装
- 插件,D6.3xL6mm
- 包装方式
- 袋装
- 商品毛重
- 1克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 固态电容 | |
| 容值 | 100uF | |
| 精度 | ±20% | |
| 额定电压 | 25V | |
| 纹波电流 | 3A@100kHz | |
| 等效串联电阻(ESR) | 20mΩ@100kHz |
| 属性 | 参数值 | |
|---|---|---|
| 类型 | 聚合物 | |
| 脚间距 | 2.5mm | |
| 电容体直径 | 6.3mm | |
| 电容体长度 | 6mm | |
| 工作寿命 | 2000hrs@125℃ | |
| 工作温度 | -55℃~+125℃ |
商品概述
固态铝电解电容，系列规格为RA 25V100μF 6.3X6mm。产品结构包括阳极箔（高纯铝化成箔）、阴极箔（高纯铝碳箔）、导针（高纯铝，引线为镀锡铜包钢线）、电解纸（马尼拉麻）、胶盖（橡胶）、铝壳（高纯铝，涂层铝壳）。
