温馨提醒：图片仅供参考，商品以实物为准
DHG016M108H162S1AA
1000uF ±20% 16V
- 描述
- 16V 1000UF 直插铝电解电容
- 品牌名称
- KNSCHA(科尼盛)
- 商品型号
- DHG016M108H162S1AA
- 商品编号
- C46551013
- 商品封装
- 插件,D10xL16mm
- 包装方式
- 袋装
- 商品毛重
- 1.72152克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 直插铝电解电容 | |
| 容值 | 1000uF | |
| 精度 | ±20% | |
| 额定电压 | 16V | |
| 纹波电流 | 1.25A@100kHz | |
| 等效串联电阻(ESR) | 50mΩ@100kHz |
| 属性 | 参数值 | |
|---|---|---|
| 脚间距 | 5mm | |
| 电容体直径 | 10mm | |
| 电容体长度 | 16mm | |
| 工作寿命 | 5000hrs@105℃ | |
| 工作温度 | -40℃~+105℃ |
