温馨提醒：图片仅供参考，商品以实物为准
DHG200M106G120S1AA
10uF ±20% 200V
- 描述
- 200V 10UF 直插铝电解电容
- 品牌名称
- KNSCHA(科尼盛)
- 商品型号
- DHG200M106G120S1AA
- 商品编号
- C46550796
- 商品封装
- 插件,D8xL12mm
- 包装方式
- 袋装
- 商品毛重
- 0.891933克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 直插铝电解电容 | |
| 容值 | 10uF | |
| 精度 | ±20% | |
| 额定电压 | 200V | |
| 纹波电流 | 220mA@100kHz | |
| 等效串联电阻(ESR) | 2.25Ω@100kHz |
| 属性 | 参数值 | |
|---|---|---|
| 脚间距 | 3.5mm | |
| 电容体直径 | 8mm | |
| 电容体长度 | 12mm | |
| 工作寿命 | 5000hrs@105℃ | |
| 工作温度 | -40℃~+105℃ |
优惠活动
购买数量
(500个/袋，最小起订量 10 个)个
起订量：10 个500个/袋
总价金额：
￥ 0.00近期成交2单
