- 引脚图
- 焊盘图
温馨提醒：图片仅供参考，商品以实物为准
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 功率电感 | |
| 电感值 | 10uH | |
| 精度 | ±20% | |
| 额定电流 | 2.08A |
| 属性 | 参数值 | |
|---|---|---|
| 饱和电流(Isat) | 2.47A | |
| 直流电阻(DCR) | 65.6mΩ | |
| 类型 | - | |
| 车规等级 | - |
