XC21M4-52.000-F10NNHPL
2016 4P 52MHz 10pF ±10ppm -20~+70℃ (±10ppm)
SMT扩展库SMT补贴嘉立创PCB免费打样
- 描述
- 全国产化,超小超薄,高精度,封装:2016,4P,频率:52MHz,负载电容:10pF,常温频差:±10ppm,工作温度:-20℃~+70℃,频率稳定度:±10ppm,型号升级变更为:0121M4-52.000F10HPNNL
- 品牌名称
- HCI(杭晶)
- 商品型号
- XC21M4-52.000-F10NNHPL
- 商品编号
- C3034316
- 商品封装
- SMD2016-4P
- 包装方式
- 编带
- 商品毛重
- 0.015克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 无源晶振 | |
| 晶振类型 | 贴片晶振 | |
| 频率 | 52MHz | |
| 常温频差 | ±10ppm |
| 属性 | 参数值 | |
|---|---|---|
| 负载电容 | 10pF | |
| 频率稳定度 | ±10ppm | |
| 等效串联电阻(ESR) | 60Ω | |
| 工作温度 | -20℃~+70℃ |
