KM1C332MI250A00CV0
3300uF ±20% 16V
SMT扩展库SMT补贴嘉立创PCB免费打样
- 描述
- 特性：宽温度产品,105°C,1000小时寿命,体积小,容量大。符合ReHS指令。应用：开关电源。适配器
- 品牌名称
- HUAWEI(华威集团)
- 商品型号
- KM1C332MI250A00CV0
- 商品编号
- C2912370
- 商品封装
- 插件,D12.5xL25mm
- 包装方式
- 袋装
- 商品毛重
- 4.1克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 直插铝电解电容 | |
| 容值 | 3300uF | |
| 精度 | ±20% | |
| 额定电压 | 16V | |
| 纹波电流 | - | |
| 等效串联电阻(ESR) | - |
| 属性 | 参数值 | |
|---|---|---|
| 脚间距 | - | |
| 电容体直径 | 12.5mm | |
| 电容体长度 | 25mm | |
| 工作寿命 | 1000hrs@105℃ | |
| 工作温度 | -40℃~+105℃ |
