商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 自恢复保险丝 | |
| 耐压(Vmax) | 12V | |
| 最大电流(Imax) | 40A | |
| 保持电流(Ihold) | 1.5A | |
| 跳闸电流(Itrip) | 3A | |
| 消耗功率(Pd) | 600mW | |
| 初始态阻值(Rmin) | 40mΩ |
| 属性 | 参数值 | |
|---|---|---|
| 跳断后阻值(R1max) | 130mΩ | |
| 动作时间 | 1s | |
| 工作温度 | -40℃~+85℃ | |
| 长度 | 3.5mm | |
| 宽度 | 1.8mm | |
| 高度 | 1.8mm | |
| 脚间距 | - |
