LQP03TQ1N8B02D
±0.1nH 1.8nH
SMT扩展库PCB免费打样
私有库下单最高享92折
- 品牌名称
- muRata(村田)
- 商品型号
- LQP03TQ1N8B02D
- 商品编号
- C237363
- 商品封装
- 0201
- 包装方式
- 编带
- 商品毛重
- 0.008克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 贴片电感 | |
| 电感值 | 1.8nH | |
| 精度 | - | |
| 额定电流 | 650mA | |
| 饱和电流(Isat) | - |
| 属性 | 参数值 | |
|---|---|---|
| 直流电阻(DCR) | 100mΩ | |
| 品质因数 | 17@500MHz | |
| 自谐振频率 | 15GHz | |
| 车规等级 | - | |
| 类型 | 厚膜电感 |
