温馨提醒：图片仅供参考，商品以实物为准
JNJ-3030JI0113W140/35mil/845-860nm
3030晶元35mil平面红外灯源845-860nm
SMT扩展库SMT补贴嘉立创PCB免费打样
- 描述
- 产品尺寸：3.0x3.0x0.6
- 品牌名称
- JNJOPTO(强生光电)
- 商品型号
- JNJ-3030JI0113W140/35mil/845-860nm
- 商品编号
- C18199779
- 商品封装
- SMD3030-2P
- 包装方式
- 编带
- 商品毛重
- 0.074605克(g)
商品参数
| 属性 | 参数值 | |
|---|---|---|
| 商品目录 | 红外发射管 | |
| 正向压降(Vf) | 1.5V~2.3V；1.4V~2.1V | |
| 波长 | 850nm | |
| 辐射强度 | 82mW/sr；160mW/sr | |
| 正向电流 | 1A |
| 属性 | 参数值 | |
|---|---|---|
| 直流反向耐压(Vr) | 5V | |
| 视角 | 125° | |
| 工作温度 | -40℃~+100℃ | |
| 半波宽 | 60nm |
